Industrial Control PCB Assembly for Automation and Process Control

OrinewPCB provides industrial control PCB assembly for high reliability control systems used in manufacturing, energy and automation industries.

Our control PCBs are built with industrial-grade materials to withstand extreme temperatures, vibration and electrical noise, maintaining consistent performance in harsh environments.

We offer PCB assembly services from prototype PCB builds to volume PCB assembly, with IPC-A-610 Class 3 compliance for industrial control components.

  • Industrial control PCB assembly with copper weights from 0.5 to 5 oz

  • ISO, UL, and RoHS certified PCB assembly manufacturer facilities

  • Advanced SMT and THT assembly process for complex control systems

GET YOUR QUOTE!

Click or drag a file to this area to upload.

Precision Industrial Control PCB Assembly for Demanding Applications

Industrial control PCB assembly and OEM industrial wire harness solutions support the reliable operation of industrial control components in automation, process control and heavy duty manufacturing equipment.

These control PCBs combine high quality PCB material selection with IPC Class 3 workmanship, allowing for continuous operation in industrial settings that are exposed to vibration, electrical interference and extreme temperatures.

Our industrial Control PCB Assembly Capabilities

OrinewPCB’s industrial control PCB assembly combines high precision placement, advanced quality control and robust material selection to deliver reliable industrial control PCBs for a variety of industrial control applications.

Our SMT lines achieve placement accuracy within ±30 µm and support components down to 01005 packages.

For industrial control components requiring high density layouts, we handle BGA pitches down to 0.2 mm and QFP spacing as fine as 0.25 mm.

Copper thickness from 0.5 oz to 5 oz is supported, with heavy copper up to 20 oz for high current control PCB designs.

We assemble embedded wireless modules for industrial control, including ESP32, ESP8266, Quectel, Fibocom and Simcom.

RF layouts follow 50 ohm antenna feed geometry with keep‑out, shield can footprints and low loss dielectrics where needed.

We validate radio paths with S11 checks, conduct power measurements, and connectorized test points for repeatable RF calibration.

Through-hole technology (THT) assembly is available for components demanding enhanced mechanical strength in industrial control systems often subjected to vibration, shock and thermal cycling.

Drilling capabilities include finished hole sizes down to 0.15 mm for boards ≤1.6 mm thick, with aspect ratios up to 12:1 for plated through-holes.

We offer HDI PCB structures with via-in-pad, stacked microvias, and blind/buried via configurations for compact industrial control board designs.

These support signal integrity and space optimization in complex industrial control equipment, especially where EMI control is necessary.

For space-constrained control enclosures, we assemble flexible PCB and rigid-flex PCB designs using polyimide and high Tg FR4 substrates.

Thickness ranges from 0.2 mm to 6.0 mm with warp and twist ≤0.7%, ensuring dimensional stability during the assembly process.

We integrate SMT and THT on the same control PCB when both miniaturization and mechanical robustness are required.

This approach is often used in process control systems and motion control applications where signal processing circuits and high power connectors must coexist.

Assemblies support CAN, RS485, Ethernet, Modbus and industrial Wi Fi or BLE for plant networks. Designs apply galvanic isolation, TVS protection, and common‑mode chokes to protect control equipment in noisy plants.

We route differential pairs to target impedance and specify transformer‑isolated magnetics for reliable links.

Surface finishes include leaded HASL, lead-free HASL, ENIG (0.05 to 0.2 µm Au over 3 to 6 µm Ni), OSP, immersion tin, and immersion silver.

These are selected according to industrial processes and corrosion resistance needs. Conformal coatings protect against dust, moisture, and chemicals in harsh industrial settings.

Every industrial control PCBA undergoes 100% automated optical inspection (AOI), X-ray inspection for hidden joints and either flying probe or in-circuit testing.

Extra tests include thermal shock, solderability, impedance verification and microsection analysis to confirm copper plating quality.

For connected control PCB assemblies, we add RF and protocol tests. That includes over the air checks, conducted sensitivity sweeps, link margin assessments, and network stack validation for CAN, RS485, and Ethernet. We provide log files and pass criteria with each batch.

Our team can handle complete PCB assembly solutions, from fabrication to sourcing components, to final assembly and packaging.

Our production capacity of 600,000 components per hour supports both prototype PCB assembly and high volume PCB assembly manufacturing with consistent quality control.

Why Choose OrinewPCB for Your Industrial Control PCB Assembly?

Manufacturing and Assembly Services Under One Roof

We cover every aspect of your project from PCB fabrication to final testing.

This one-stop PCB approach simplifies supply chain management and reduces lead times for industrial control components.

IPC Class 3 and ISO-Certified Quality Control

Our facilities follow IPC-A-610 Class 3 workmanship standards and hold ISO 9001 and ISO 14001 certifications.

This ensures every industrial control PCB assembly meets the reliability requirements for industrial control systems often used in harsh environments.

Industrial-Grade Material and Component Sourcing

We source all components from authorized distributors such as Mouser, Digi-Key and Arrow.

Our team carefully selects industrial grade electronic components with extended temperature ranges and vibration resistance.

Fast Turnaround for Prototypes and Volume PCB Assembly

Whether you need a prototype PCB for testing or volume PCB assembly manufacturing, we’re ready to deliver.

We offer prototyping within 3 weeks and mass production in 4 to 5 weeks. Expedited lead times can be arranged for urgent industrial control PCB assembly projects.

Advanced Testing and Inspection Capabilities

Every industrial control PCBA undergoes AOI, X-ray inspection, in-circuit testing and functional testing under simulated operating conditions.

This helps our team of engineers to confirm their performance before shipping.

Responsive Technical Support

Our experienced engineering team supports you through PCB design review, DRC checks, and manufacturing process optimization.

This thorough approach ensures your industrial control board meets all performance and compliance requirements.

What Is Industrial Control PCB Assembly?

Industrial control PCB assembly is the process of building printed circuit board assemblies specifically designed for industrial control systems and automation equipment. Unlike consumer-grade PCBs, teams engineer these control PCBs to operate reliably in harsh industrial settings, withstanding vibration, extreme temperatures, dust, moisture and electromagnetic interference.

This type of PCB assembly integrates industrial control components like microcontrollers, communication modules, power regulation circuits and sensor interfaces into a single, high-reliability control PCB.

Features of Industrial Control PCBs

Industrial control PCBs are engineered for reliability, safety and performance in industrial control systems often operating in harsh environments. These features ensure stable operation, long service life and support Industry 4.0 programs.

Extended Temperature Range Components (-40°C to +125°C)

We select industrial grade electronic components rated for extreme temperature ranges to support operation in hot manufacturing floors, outdoor installations or cold storage environments.

These components maintain electrical stability under continuous load, preventing control system failures caused by thermal stress.

High Copper Weights for Power Handling

Control PCBs can be specified with copper thickness up to 20 oz (700 μm) for high current paths used in motion control, industrial automation, and power distribution systems.

Heavy copper improves heat dissipation and allows smaller trace widths without sacrificing current-carrying capacity.

Polyimide, PTFE & Metal-Core Substrate Options

For specific industrial control applications, we offer high temperature polyimide substrates, low loss PTFE laminates for high frequency PCB designs, and metal-core PCBs for efficient thermal management.

Substrate selection is matched to the operating conditions, electrical requirements and mechanical stresses of the industrial control board.

Long Lifecycle Component Strategies

Because industrial control PCBs are often used in equipment with 15 to 20 year service lifespans, we implement component obsolescence management.

This includes selecting components with stable supply roadmaps, qualifying alternative parts and stocking key PCB components for long term production continuity.

Vibration-Resistant Mounting Techniques

To withstand mechanical shock and vibration in industrial settings, we use reinforced through-hole soldering for connectors, additional mechanical support for heavy components and rigid-flex PCB sections where movement is unavoidable.

These measures protect solder joints and maintain electrical connectivity in demanding environments.

Industrial Control PCB Assembly FAQs

Can you assemble both SMT and THT on the same board?

Yes, we offer mixed technology PCB assembly for industrial control PCBs, combining SMT for compact, high-density circuits with THT for mechanically robust industrial control components such as connectors, relays and transformers.

Every industrial control PCB assembly undergoes 100% automated optical inspection (AOI), X-ray for hidden joints, and either flying probe or in-circuit testing. Our team also performs functional testing under simulated operating conditions to verify performance in industrial control applications.

Yes, we source all electronic components from authorized distributors, focusing on industrial-grade parts rated for extended temperature ranges, vibration resistance, and long lifecycle availability to match the demands of industrial control systems.

Yes, we provide industrial control PCB assembly solutions that integrate into smart factory environments. Designs can support predictive maintenance sensors, real-time data analytics and secure network protocols for remote monitoring. For advanced applications, we can incorporate interfaces for digital twin connectivity, enabling synchronized virtual models of your control systems.
